l 특징 :
-> The interior fittings are entirely made of stainless steel offering a stor age area of 0.7m2 (Pharma 280), 2.07m2
(Pharma 600), 4.14m2 (Pharma 1300) and 6.21m2 (Pharma 2000) with 2, 6, 12 or 18 loose shelves which are supplied as a
standard feature.
-> The working range of the cabinets easily meets the requirements of the ICH Guideline Q1A.
-> The cabinets also permit the implementation of tests with other specifications in the performance range of the respective
system.
-> Controlling of temperature and humidity is performed with highly precise sensors in combination with a specially designed
control unit.
The control system responds quickly in order to correct setpoint variations caused by
-> The influence of the cabinet’s contents (absorption or emission of water vapour by the test specimens or their packaging)
-> External influences (e. g. laboratory temperature, opening of door).
l Standard Version :
-> Digital measuring and control system Simpac* 3.5" TFT-colour touch screen display
-> Ethernet interface
-> Lockable doors
-> Password protected control panel
-> Door contact switch
-> 6 feet (Pharma 280) or 4 castors, 2 of which with brakes (Pharma 600, 1300, 2000)
-> stackable (Pharma 280)
-> Water tank, 13 l (Pharma 280) or 19 l (Pharma 600, 1300, 2000) with automatic and manual water supply of demineralised
humidification water
-> Air-cooled refrigeration unit with low noise emission
-> Patented vapour humidification system (Sterile Steam System)
l Options :
-> Colour touch panel
-> Software package Simpati* Pharma for recording and processing of measurement values
-> Networking of several systems
-> Serial interface RS 232 C
-> Registration of temperature and humidity
-> Additional temperature and humidity sensor
-> Acoustic and optical warning signal
-> Refrigeration unit, water-cooled
-> Glass door, heated (Pharma 600, 1300 and 2000)
-> Demineralisation unit with exchangeable cartridges for connection to domestic water supply
-> Additional shelves
-> Additional entry ports
-> Height-adjustable feet (Pharma 600, 1300 and 2000)
-> Qualification documentation for Pharma test system and Simpati* Pharma software
-> Special voltage
-> Analog outputs
