Technical Data | ||||
---|---|---|---|---|
Product Name | SUK 150 W/L | SUK 250 W/L | SUK 350 W/L | |
Working temperature min. | °C | -40 | -50 | -70 |
Working temperature max. | °C | 150 | 150 | 150 |
Heat transfer liquid | Water, water/glycol, thermal oil, special liquids | Water, water/glycol, thermal oil, special liquids | Water, water/glycol, thermal oil, special liquids | |
Heater power max. | kW | 9 | 18 | 50 |
Cooling output at 0 °C | kW | 5 | 15 | 35 |
Cooling output at -80 °C | kW | 0.50 | ||
Feed pump pressure capacity max. | m³/h | 2 | 6 | 20 |
Technical Data | ||||
---|---|---|---|---|
Product Name | SUK 400 W/L | SUK 600 W/L | SUK 1000 W/L | |
Working temperature min. | °C | -100 | -100 | -100 |
Working temperature max. | °C | 150 | 150 | 150 |
Heat transfer liquid | Water, water/glycol, thermal oil, special liquids | Water, water/glycol, thermal oil, special liquids | Water, water/glycol, thermal oil, special liquids | |
Heater power max. | kW | 60 | 120 | 240 |
Cooling output at 0 °C | kW | 120 | 240 | 300 |
Cooling output at -80 °C | kW | 5 | 10 | 20 |
Feed pump pressure capacity max. | m³/h | 30 | 50 | 80 |
